| PARTS | MATERIAL SCIENCE | FUNCTION |
|---|---|---|
| Positive and negative plate | ★ Lead calcium alloy grate coated with active material | ☆ Guarantee sufficient capacity ☆ Guarantee life ☆ Reduce self discharge |
| A partition | ★ High temperature resistant superfine glass fiber ★ PVC and PE |
☆ Prevention of positive and negative plate short circuit ☆ Adsorptive electroliquid ☆ Anti active material falling off from the surface of the extruded plate |
| Electrohydraulic | ★ Dilute sulfuric acid ★ Colloidal dilute sulfuric acid |
☆ Participate in the reaction of positive and negative active substances |
| Shell cover | ★ ABSAnd resistance ABS | ☆ A polar group containing a positive or negative plate and a diaphragm ☆ Enough strength to withstand the internal pressure of the battery |
| Safety valve | ★ Good insulation ★ Anti aging synthetic rubber |
☆ If the pressure inside the battery exceeds the standard, release the gas and
make it normal. ☆ Prevent oxygen from entering the battery |
| terminal | ★ Made of copper and lead alloy ★The terminal part is sealed by double seal and O ring ★Sealant, red in positive pole, black in negative ★The selectable terminal is the internal thread type |
☆ Large area terminals improve the performance and reliability of high
current discharge. ☆ Good sealing of terminal position ☆ Make the connecting piece easy to load and unload |
| Characteristic | Structure | Purpose |
|---|---|---|
| No maintenance needs no fluid; | Component... Material | UPS uninterruptible power supply; |
| A wide range of adaptation to temperature; | Active substance... Oxide | EPS fire-fighting standby power supply; |
| Long service life; | Battery... Polyethylene | Safety and protection alarm system; |
| Safety and explosion-proof; | Polar plate... Lead | Post and telecommunications communication equipment; |
| No free electrolyte, 90 degrees side down can still be used | Battery cover... Polyethylene | Electronic instruments and instruments; |
| The internal resistance is small, and the high current discharge performance is good. | Sealant... Epoxy resin | Micro electric tools; |
| Small self discharge; | Safety valve... Rubber | Portable electronic equipment; |
| Electric power plant, easy to use; | Septum... Glass fiber | Emergency lighting system; |
| Special formula, deep discharge recovery performance is good. | Terminal... Copper / lead | Power system; |
| The products are certified by CE. ROHS, and all batteries meet the national standard. | Electrolyte... Sulfuric acid | Electric toys; |
| Camera Equipment; | ||
| Control system DC screen; | ||
| Medical equipment, etc. |
| Characteristic | Structure | Purpose |
|---|---|---|
| The unique alloy grid design ensures low self discharge rate. | Component... Material | Green new energy series; |
| Oxygen recombination technology, sealing and maintenance free; | Active substance... Oxide | Solar power generation system; |
| High purity raw material, stable quality, high reliability; | Battery... Tight ethylene | Wind power generation system; |
| The unique formula technology enhances the ability of over charging and the ability of over discharge recovery. | Pole... Lead | Wind and scenery complementary power generation system; |
| High quality AGM separator allows battery life to last longer. | Battery cover... Polyethylene | Solar power station; |
| Without free electrolyte, the side 90 degrees can still be used. | Sealant... Ring resin | UPS\EPS backup power supply; |
| Electric power plant, easy to use; | Safety valve... Rubber | Solar energy signal station; |
| The range of working temperature is wide: -20*C~ 50C | Septum... Glass fiber | Solar energy measurement station; |
| Terminal... Copper / lead | The solar early-warning alarm system; | |
| Electrolyte... Sulfuric acid | Solar traffic light traffic light | |
| The signal tower of the navigation system; | ||
| Huimin project solar street lamp and so on |
| Characteristic | Structure | Purpose |
|---|---|---|
| The unique alloy grid design ensures low self discharge rate. | Components... Raw materials | Green new energy series; |
| The gas recombination technology has high sealing efficiency and no acid mist precipitation. | Active substance... Oxide | Communication system base station; |
| High purity raw materials, deep discharge resistance, long cycle life. | Battery... Polyethylene | Microwave / switch base station; |
| The unique formula technology enhances the ability of over charging and the ability of over discharge recovery. | Pole... Lead | Radio and radio stations; |
| Special design and high reliable sealing technology make the battery safe, environmentally friendly and free of maintenance. | Battery cover... Polyethylene | Power plant / power transmission and transformation system; |
| The colloidal electrolyte formula does not cause stratification inside the battery. | Sealant... Huai oxo resin | Solar energy and wind power system; |
| Electric power plant, easy to use; | Safety... Glue | The application of deep circulation equipment in the banking system |
| The high rate discharge performance is enhanced by tight assembly technology. | Clapboard... Glass fiber | Signal system emergency lighting system; |
| The range of working temperature is wide: -20C~50*C | Rock... Copper / lead | Solar street lamp project; |
| Electrolytes... Condensate acid | Mountain flood disaster monitoring and warning system; | |
| Meteorological survey station; | ||
| Nautical system, etc. |
